C22 Access Controller

Model No: C22

2-door access control panel

The C22 Access Controller is a standalone 2-door access control panel supporting up to 500 users with fingerprint, card, and PIN authentication modes. Managing access for two independent doors, it features real-time event logging, anti-passback, and time-zone scheduling. Ideal for small office environments requiring reliable door access management.

TCP/IP

RS485

Technical Specifications

Capacity & Storage

Door Capacity

2 doors

Card Capacity

30,000

Transaction Records

100,000

Access & Security

Reader Ports

4 Wiegand reader ports

Input

8 alarm inputs

Output

4 relay outputs

Tamper Detection

Yes

Connectivity

Communication

TCP/IP, RS485

Power

Power Supply

DC 12V / 3A

Operating Temperature

-10°C to 55°C

Physical

Dimensions

220 × 150 × 45 mm

C22 Access Controller

Reliable | Affordable | Made for India

WhatsApp Us Get a Quote

Downloads & Resources

Catalogue

Device Introduction

Connection Diagram
