C334 Access Controller

Model No: C334

34-door access control panel

Enquire on WhatsApp Get a Quote
C334 Access Controller
C334 Access Controller

C334 Access Controller

The C334 Access Controller is an advanced multi-door controller supporting up to 50,000 cardholders with real-time network management. Managing up to 4 doors with features such as wiegand input, dry contact relay output, and RS-485 device connectivity, it is well-suited for large commercial buildings and industrial facilities requiring centralised access management.
TCP/IP
RS485

Technical Specifications

Capacity & Storage

Door Capacity

4 doors

Card Capacity

10,000

Transaction Records

100,000

Access & Security

Reader Ports

4 Wiegand reader ports

Input

8 alarm inputs

Output

4 relay outputs

Connectivity

Communication

TCP/IP, RS485

Power

Power Supply

DC 12V / 3A

Operating Temperature

-10°C to 55°C

Physical

Dimensions

220 × 155 × 45 mm

C334 Access Controller

C334 Access Controller

Reliable  |  Affordable  |  Made for India

WhatsApp Us Get a Quote

Downloads & Resources

Catalogue
Device Introduction
Connection Diagram
