Card Reader SA221
Model No: SA221
RFID card reader for access control
Card Reader SA221
The SA221 is a slim-profile card reader supporting 125 kHz proximity cards with Wiegand 26-bit output. Its low-profile metal housing installs easily on door frames and wall surfaces, making it suitable for office and light industrial access control applications. Compatible with all BioMax access controllers.
Technical Specifications
Connectivity
Frequency
125 kHz
Read Range
5–10 cm
Access & Security
Output
Wiegand 26
Power
Operating Voltage
DC 12V
Operating Temperature
-20°C to 70°C
Display & Interface
LED Indicator
Yes + buzzer
Physical
Dimensions
80 × 50 × 15 mm
IP Rating
IP65
