V-R12 RFID Reader
Model No: V-R12
RFID card reader for access control systems
V-R12 RFID Reader
The V-R12 is a compact RFID card reader for access control integration, supporting both 125 kHz EM and 13.56 MHz MIFARE card formats. With a standard Wiegand 26/34 output, it connects directly to BioMax access controllers, panel-based systems, and third-party controllers. Weatherproof construction makes it suitable for outdoor installations.
Technical Specifications
Connectivity
Frequency
125 kHz / 13.56 MHz
Read Range
3–10 cm
Access & Security
Output
Wiegand 26 / Wiegand 34
Power
Operating Voltage
DC 5V–12V
Operating Temperature
-20°C to 70°C
Display & Interface
LED Indicator
Bi-colour LED + buzzer
Physical
Dimensions
74 × 44 × 14 mm
IP Rating
IP65
