AI Face Recognition Terminal
SpeedFace 5 is the face recognition product with high performance and high reliability, which depends on the deep learning algorithm, also having the characteristics of quick recognition speed and high accuracy. This product supports 1:1 and 1:N mode, with embedded card reader.


The test method for 99.99% recognition accuracy is: to compare the face in database (each person has multi images in the database) with other faces, the person with the highest score is the one to be identified or not, if he is, then the recognition is accurate.

Face Recognition Terminal


Face Capacity : 3000

Card Capacity : 3000

Max User : 3000

Logs Capacity : 50,000

Accuracy : 99.27%

Living body detection : Support


Display screen : 5-inch IPS touch screen display

Resolution : 480 * 854

System parameters

Operating system : Linux

CPU : Dual-core ARM Cortex-A7@ 900MHz

Storage 512MB RAM, 4GM ROM



Relay : Yes

Wiegand out : Yes

Card Option : Mifare

General parameters

Power : 12V DC / 2A

Working temperature : -10°C~50°C

Dimension : 185.8 x 93.7 x 22.5 mm
