AI Face Recognition Terminal
Speed Face 5 TM is the face recognition product with high performance and high reliability, which depends on the deep learning algorithm, also having the characteristics of quick recognition speed and high accuracy. This product supports 1:1 and 1:N mode.
based on the person's facial texture, shape and movement.


Face Recognition Terminal


Face Capacity : 50,000

Max User : 50,000

Logs Capacity : 2,00,000

Living body detection : Support

Sensor : IR array Sensor

Stranger detection : Support

Recognition distance configuration : Support

Remote update : Support

Deployment : Public network, LAN


Display screen : 5-inch IPS LCD touch screen

Resolution : 854 * 480

System parameters

Operating system : Linux

CPU : Dual-core ARM Cortex



Relay output : 1-way (DOOR_NO, DOOR_COM, DOOR_NC)

Network interface : 1-way Ethernet (RJ45, 100M)

TTL serial port : Embedded with our card plate

Wi-Fi : Standard: IEEE 802.11b/g/n

Wiegand Output : Yes

Reset interface : Reset button

USB interface : 1-way Type-A

General parameters

Power : DC 12V/2A

Device Working Temp. : -10°C~50°C

Environment for Temp. Measurement : 22°C ~ 32°C

Temp. Measurement Distance : 30cm

Temp. Measurement Range : 35.5°C~42°C (95.9°F~107.6°F)

Working humidity : 10%~90%

Dimension 216.00 x 90 x 25 mm
