AI Face Recognition Terminal


SpeedFace 8 is the face recognition product with high performance and high reliability, which depends on the deep learning algorithm, also having the characteristics of quick recognition speed and high accuracy. This product supports 1:1 and 1:N mode, as well as external card reader.

The test method for 99.99% recognition accuracy is: to compare the face in database (each person has multi images in the database) with other faces, the person with the highest score is the one to be identified or not, if he is, then the recognition is accurate.

Face Detection

Access Control

WiFi Connectivity

LAN Connectivity

USB Connectivity

RFID Card Detection

Face Recognition Terminal


Face Capacity : 1,00,000

Max User : 1,00,000

Logs Capacity : 2,00,000

Living body detection : Support

Stranger detection : Support

Recognition distance configuration : Support

Remote update : Support

Deployment : Public network, LAN


Display screen : 8-inch IPS all-sight LCD touch screen

Resolution : 1280 * 800

System parameters

Operating system : Linux

CPU : Dual-core ARM Cortex



Serial communication interface : 1-way RS-232

Relay output : 1-way

Wiegand output : 1-way Wiegand 26/34

Network interface : 1-way 100M Ethernet

Wi-Fi : IEEE 802.11b/g/n

Wiegand Output : Yes

Reset interface : Reset button

USB interface : 1-way Type-A

Audio output : 1-way 3.5mm standard interface

Card reader interface : IC series: external access of our IC card module, IC card (reading frequency:13.56MHz, including ID card, CPU card and M1)

General parameters

Protection grade : IP66

Power : DC 12V/2A

Working temperature -10°C~50°C

Working humidity : 10%~90%

Dimension : 270 * 130 * 90 mm
