N-X990
Model No: N-X990
Most versatile fingerprint time attendance & access control
N-X990
N-X990 is one of the most versatile models in the industrial market — used in Corporate Offices, Industrial Areas, Construction Sites, Schools and Colleges. Powered by a Linux OS and Advance CPU, it supports versatile connectivity and features. The powerful sensor verifies multiple types of fingers — mehndi, colour, ink, rough, and dry — with the same accuracy. Inbuilt battery backup keeps the device running even during power cuts.
Function Shortcut Keys allow direct access to frequently used options. Time Zone feature lets you create and assign different time zones to different employees. Multiple Admins with different roles can be created for security. WiFi + TCP/IP + RS485 connectivity. GPRS + GPS optional — track device location and get 4G connectivity. Canteen Management: connect a thermal printer via RS232 for canteen use. Anti-Passback feature supported. Centralized control of multiple branches from head office — expire user, online enrollment, upload/delete users.
Specifications
- Fingerprint Capacity: 10,000
- Card Capacity: 10,000
- User Capacity: 10,000
- Log Capacity: 1,50,000
- Password Capacity: 10,000
- Communication: TCP/IP, WiFi, RS232/485, USB Host & Client
- Push Data: Yes
- OS: Linux
- 4G GPRS: Optional
- Display: 3.2" TFT LCD Color Screen
- Voice: 16-bit Hi-Fi voice & sound indication
- Language: English
- Thermal Printer: Optional (RS232)
- FAR: 0.00001%
- FRR: 0.001%
- Sensor: 500 DPI
- Identification: Fingerprint, Card, PIN
- Wiegand: Input/Output
- Relay: Yes
- Access Control: RS485 Reader, Wiegand Reader, Remote, Push Button, No Touch
- Battery Backup: Optional
- Operating Temperature: 0°C ~ 50°C
- Power: 12V DC / 2A
- Dimensions: 215 × 160 × 45 mm
Technical Specifications
Capacity & Storage
Fingerprint Capacity
10,000
Card Capacity
10,000
Transaction Records
200,000
Face Capacity
2,000
Connectivity
Communication
TCP/IP, RS485, Wiegand
Display & Interface
Display
3.5" TFT Color Touch Screen
Biometrics
Verification Speed
< 1 second
Fingerprint Sensor
Optical
Identification Methods
Fingerprint, Face, RFID Card, Password
Power
Power Supply
DC 12V / 3A
Operating Temperature
-10°C to 60°C
Physical
Dimensions
205 × 80 × 46 mm
